FR GRADE Fireproof Aluminum Composite Panel 4mm Thickness PVDF Coating

Minimum Order Quantity : 600SQM Price : 8-15
Packaging Details : Nude Packing or Wooden Pallets Delivery Time : 15-20days
Payment Terms : T/T, L/C Supply Ability : 1000000 Sheets Per Month
Place of Origin: CHINA Brand Name: ALUDONG
Certification: CE,SGS,ISO Model Number: ALD

Detail Information

Surface Treatment: PVDF Coated Usage: Fireproof,Fire-Retartant Non-Combustible
Color: Customer's Requirements Size: 1220*2440mm,Customized
Panel Thickness: 4mm Aluminum Thickness: 0.21-0.50mm
Standard Size: 1220*2440mm Width: 1220mm,1500mm
Coating: PVDF Length: 2440mm (As Requested)
Core Material: Fire Retardant Material: Aluminum
Aluminium Thickness: 0.21mm,0.30mm,0.40mm,0.50mm
High Light:

Fireproof Aluminum Composite Panel PVDF Coating

,

FR GRADE Fireproof Aluminum Composite Panel

,

Fireproof Aluminum Composite Panel 4mm thickness

Product Description

Introduction

1. General description

ALUDONG is primarily specializing in marketing and manufacturing aluminium composite panels. All purpose adhesive, super glue, silicone sealant, and aluminium plate, etc. can also be provided here.



2. Classification

As we have mentioned before, our aluminium composite panels fall into five primary categories, that is, internal wall panels, external wall panels, wooden grain panels, granite panels and fire resistance panels. There are totally hundred of types of aluminium plastic composite panels, with variety of colors for your option.

3. Raw materials and production techniques

Composed of superior quality antirust alloy sheets and high intensity polyethylene core sheets, and coated with world-class fluorocarbon resin, the aluminium composite panel quality is highly ensured. Additionally, our composite panels are made strictly in accordance with international standard ACP production standard. Relying on our adoption of high quality raw material and advanced production techniques, all our aluminium composite panels feature strong weather resistance, uniform coating, smooth and even surface, and more.



Structure

1. Protective film
2. PVDF clear coating
3. PVDF top coating
4. PVDF primer
5. Chromate treatment
6. aluminium skin
7. Chromate treatment
8. Bonding lamination layer
9. Nontoxic PE core material
10. Optional fire resistant and nontoxic PE core material
11. Optional back coating

FR GRADE Fireproof Aluminum Composite Panel 4mm Thickness PVDF Coating 0

Characteristics



1. Economy
Due to our adoption of high quality coatings, our aluminium composite panels are dispensed with frequent maintenance, thus saving a lot on maintenance cost. Hence, our composite panels are good decorative building material for high-rise buildings. With regard to cities and regions with serious environment pollution, it is recommended to clean and maintain aluminium composite panels in a few years' time. Our panels are easy to be cleaned. They can be cleaned by neutral cleaning agent and clean water, and come out to be fairly new after cleaned.
2. Durability
Fluorocarbon coated aluminium composite panels are characterized by long service life, good weather resistance, high heat resistance and wear resistance, and good resistance to pollutions, and more.
3. Flatness
Our aluminium composite panels are manufactured with smooth and even surface, which can satisfy people's high demand on the appearance of modern constructions.
4. Light weight
By adopting light-weight aluminium alloy and superior quality plastics as primary raw material, aluminium composite panel is lighter than other types of decorative construction material. Hence, it is easy to install and needs shorter installation period.
5. Easy installation
Our aluminium composite panels are adaptable to various decoration requirements, because they are easy to be cut, grooved and bended.
6. Fireproofing
The exterior aluminium sheet of aluminium composite panels can effectively protect interior PE core material, because it can prevent heat conduction at the initial stage of combustion. The flame resistance of our aluminium plastic composite panels has reached international standard.
7. Design performance
aluminium composite panels can be made into different colors and styles, thus satisfying the diversified design requirements of architects.
8. Eco-friendliness
The surface coating is durable and has no changes, which produces no pollutants.

FR GRADE Fireproof Aluminum Composite Panel 4mm Thickness PVDF Coating 1

TECHNICAL PROPERTY

PHYSICAL PROPERTIES
Item Unit Thckness Standard
3MM 4MM 6MM
Density g/cm3 1.52 1.37 1.22 ASTM D792
Weight kg/m2 4.55 5.48 7.34 ASTM D792
Thermal Expansion(20-600) 10.6/oc 22 24 25 ASTM D696
Thermal Conductivity(appearance) w/m.k - 0.15-0.19 - ASTM C518
Temperature for Thermal Deformation oC - 113 - ASTM C648
Acoustic Insulation(100-3200HZ) dB 24 26 27 ASTM C413
MECHANICAL PROPERTIES
Item Unit Thckness Standard
3MM 4MM 6MM
Tensile Strength Mpa 45.8 48 38.2 ASTM D638
Yield Strength Mpa 43.4 44.2 30.4 ASTM D638
Extension Rate % 12 14 17 ASTM D638
Transverse Modulus X10Mpa 3.2 4.2 2.8 ASTM D638

Applications

1. Wall and interior decoration of air ports, docks, stations, metros, hotels, restaurants, recreation places, top-grade residence, villas, office, and many other buildings.
2. Big billboards, shop windows, roadside news kiosks, bookstalls, telephone booths, traffic sentry boxes and filling stations.
3. Internal walls, ceilings, compartments, kitchens, toilets, etc.
4. Decoration for shops, cabinets, pillars, furniture, trains, automobiles, ships and carriages, etc.
5. Renovation and reconstruction of old buildings.
6. Cleaning and dust control projects.
