3mm PE Aluminum Composite Panel Surface Brushed Anodized

Minimum Order Quantity : 600SQM Price : Negotiatable
Packaging Details : nude packing or wooden pallets Delivery Time : 10-15 days
Payment Terms : L/C, T/T, D/P, Western Union, Paypal, Money Gram, Cash Supply Ability : 1000000 per month
Place of Origin: China Brand Name: ALUDONG
Certification: CE, ASTM, ISO, Green Leaf

Detail Information

Model NO.: ZWM-8821 Width: 1220-1570mm
Color: Ral Standard Brand: Aludong
Standard Size: 1220*2440mm Length: Less Than 8000mm
Packing: Bulk Or Wooden Box Thickness: 1.5mm-8mm
Surface Treatment: PE, PVDF, Brushed, Anodized Etc Delivery Detail: Delivered Within 7 Working Days After Prepayment
Trademark: Aludong Transport Package: Fumigated Wooden Pallet
Specification: 1220*2440 Origin: Henan China
HS Code: 76061251 Port: Qingdao, China
Production Capacity: 921600 Pieces / Day Surface Finishing: Coating
Panel Thickness: 3mm Aluminum Thickness: 0.15mm
Function: Anti-static, Anti-Bacterial, Mould-proof Usage: Interior, Advertising, Printing
Certification: CE, ISO, SGS, RoHS
High Light:

Brushed PE Aluminum Composite Panel

,

3mm PE Aluminum Composite Panel

,

Anodized PE Aluminum Composite Panel

Product Description

3mm Aluminium Composite Panel Doceration Material

Product Description

Customer Question & Answer

Ask something for more details
                         ALUMINIUM COMPOSITE PANEL / ACM / ACP                                                                                   www.henanjixiang.com

1)Material:

A) Front : aluminium alloy sheet coated fluoro-carbon resin (PVDF) with Nano lacquer

B) Core: nontox low density polyethylene

C) Back: aluminium alloy sheet coated with polyester resin painting

D) Surface coating thickness: 32μ±1μ

E) Aluminium alloy: 3003 H24

F) Sheet thickness: 0.3mm,0.4mm,0.5mm



2)Dimensions

A) Thickness: 3mm,4mm,6mm,8mm,10mm

B) Width: 1220mm,1250mm,1500mm,1570mm,1800mm,2000mm(max)

C) Length: 2440mm,3050mm,3200mm( max:6000mm)

D) Weight: 5.5kg/sqm baesd on 0.5/4mm thickness

E) Standard size:1220*2440mm

F) Qty/20'fcl:4mm/2380sqm; 3mm/2977sqm

G) Non-stanard size are available according to requirement



3)Standard:

A) West Europe standard ( Germany DIN Standard);

B) The EAST Europe standard ( Russian standard );

C) The commonweathlth standard (U.K BS Standard );

D) The North America ASTM standard;



4)Features:

A) Light weight,flat surface and high strength

B) Excellent heat insulation ,sound insulation,fire-resistance,acid-resistance,alkali-resistance,weatherproofness and non-resonance

C) Various uniform colors

D) Rbright ,elegan and magnificent,fit for various designs

E) Kynar 500 PVDF resin feature strong chemical resistance,unique colors can be easily maintained



5)Applications:

  A) May be widly used in gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments

  B) An ideal decorative materials for buildings

  C) An ideal outer and inner walls

  D) Kitchen cabinees,billboards,signboards,tunnels,subway,interiors

  E) Cellings,eaves,galleries,balconies,partitions,interior decorations

  F) Telephone tooths,vehicle bodies,yachts,industrial usage etc.



Aluminum composite panel /ACP/ACM

6)SkyRainow® ACP compared with different products( Lightness / Rigidity ):

The composite structure of SkyRainbow® results in an impressive strength-to-weight ratio, even when comparing large panel sizes. Despite its low weight, which makes Sky Rainbow ® easy to transport and handle in the factory and on site, its rigidity and high strength make the panels keep their shape and remain flat, even when exposed to extreme temperature changes.
Comparison of thickness and weight of panels with equal rigidity



7)SkyRainow® ACP compared with solid aluminium: Required thickness and actual weights of panels with same rigidity

    SkyRainow® ACP Aluminium
Rigidity (E J) Section modulus Thickness Weight Thickness Weight
1250 kN cm2/m 1.25 cm3/m 3 mm 4.5kg/m2 2.7 mm 7.3kg/m2
2400 kN cm2/m 1.75 cm3/m 4 mm 5.5kg/m2 3.3 mm 8.9kg/m2



8)Skyrainbow ACP Tolerance(mm) :

Thickness ± 0.2
Width ± 2
Length ± 4
Diagonal ± 5



9)Skyrainbow ACP Physical Properties for Panel:

Panel density 5.5kg/m2
Peel Strength Average 7.0 N/mm
Tensile Strength 52.5 Mpa
Flexural Strength 100.0 Mpa
Shear Strength 28.1 Mpa



10)Physical properties for aluminium and coating:

Aluminium alloy 1100, 3003, 5005
Pencil hardness 2H
Toughness of coating 2T
Elongation 5%
Tensile strength 130 Mpa
Temperature Resistance -50°C to +90°C
Impact Strength 50kg/cm2 , no change
Boiling water resistance Boiling for 2 hrs, no change
Thermal Expansion 2.4mm/m at 100°C Temp difference
Acid Resistance Immersed in 2% HC1 for 24 hrs, no change
Alkali Resistance Immersed in 2% NaOH for 24 hrs, no change
Cleaning Resistance Cleaned 1000 times with water, no change
Oil Resistance Immersed in 20# engine oil for 24 hrs, no change
Solvent Resistance Cleaned 100 times with dimethylbenzene, no change

The competitive advantage of product line:

OEM is welcome.

Production Capacity:

Product Line Name Production Line Capacity Actual Units Produced(Previous Year)
Aluminum Composite Panels 500,000 Square Meters / Month

Export Market Distribution:

Market Revenue(Previous Year) Total Revenue (%)
North America confidential 18.0
South America confidential 9.0
Southeast Asia confidential 9.0
Oceania confidential 9.0
Western Europe confidential 45.0
Domestic Market confidential 10.0

Primary Competitive Advantages
1). 24 ACP production lines, 6 large coating lines, 3 PE film production lines
2). Big Group organization with 12 subsidiaries
3). Distributorship offered
4). All kinds of preferential terms
5). Deliver goods within 7 working days after prepayment



YOUR QUALITY, OUR HONOR, WELOME TO INQUIRY
